  • Tachometer Speedometer Tester 1967-1992 Camaro, Firebird, 1960's - early 1990's GM ( 4th Edition )
  • Digital Tachometer Speedometer Tester demonstration

    • Tachometer and Speedometer Testing tool for classic GM vehicles

    Was: $129.95
    Now: $119.95
    (2 reviews) Write a Review
    SKU:
    801105361
    Condition:
    New
    Availability:
    Order by 11am E.T. (M-F). Ships same day.
    Maximum Purchase:
    1 unit
    Shipping:
    Calculated at Checkout
    Adding to cart… category.add_cart_announcement

    Product Description

    Tachometer & Electronic Speedometer Tester for Classic GM Vehicles

    For many 1967–1992 Camaro, Firebird, Corvette, Fiero, GM truck, and other classic GM electronic gauge applications.

    This digital tester lets you power and test many classic GM tachometers and electronic speedometers on the bench or at the vehicle gauge-cluster plug. It provides the 12-volt power and adjustable pulsed signal needed to check gauge movement, circuit board response, and basic operation without needing the vehicle running.

    Our popular tester is now in its 4th Edition. It accurately replicates the signal type and frequency used by many GM tachometers and electronic speedometers from the late 1960s through the early 1990s.

    What This Tester Can Help You Do

    • Test many classic GM tachometers
    • Test many electronic speedometers that use a pulsed signal input
    • Check repaired or rebuilt gauge circuit boards before installation
    • Help separate a gauge/circuit-board issue from a vehicle wiring or signal issue
    • Provide a controlled signal for troubleshooting and repair work

    Fast Setup

    Simple setup — usually ready to test in about 1 minute.

    1. Connect the tester to the included power supply.
    2. Connect the power, ground, and signal clamps to the tachometer, speedometer circuit board, gauge-cluster plug, or test wiring.
    3. Turn the tester on.
    4. Select frequency mode and turn the knob to increase or decrease the signal frequency.

    Tester Output and Adjustments

    • Power: 12-volt DC output for powering the tachometer or speedometer circuit board
    • Signal: Low-current 12-volt pulsed DC signal
    • Frequency range: 1 Hz to 1000 Hz
    • Duty cycle: Adjustable
    • Engine range: Works with 1–12 cylinder tachometer applications
    • Reference chart: Includes frequency-to-RPM table

    Important Compatibility Note

    This tester is designed for tachometers and electronic speedometers that use an electronic circuit board or pulsed signal input. It is not intended for early mechanical gauges or coil-only tachometer designs, which are commonly found in some early 1960s and older applications.

    This tester is also compatible with many other electronic tachometers and speedometers that use a pulsed signal to operate the gauge.

    Includes

    • Digital tester
    • 120-volt AC power supply
    • Instructions

    Videos

    See the Video tab for short demonstrations showing earlier versions of this tester being used to test a speedometer and a tachometer.

    Easy checkout, fast shipping

    Other Details

    180 day Limited Warranty.

    Product Videos

    Videos Hide Videos Show Videos

    Custom Field

    Product Reviews

    Write a Review

    2 Reviews Hide Reviews Show Reviews

    • 4
      Noteworthy

      Posted by Ed on 28th Jan 2021

      The only Tach tester that I know of that can test it outside the car, works great. A dial would be better than buttons.

    • 5
      Sweet!

      Posted by Verified Customer on 13th Sep 2019

      Works great. Easy to use. Great price.

    Recommended
